the Natural Language App, part 2




In part one of this article [9] we discussed the different kinds of chatty AI interfaces and the merits of a mixed natural-language GUI interface.


Now we will dig a little deeper in what is underneath the covers of a Natural Language Application (NLA).

Natural Language Processing Components


Natural Language Processing (NLP) has been around since the 1950s. We will exclude speech-to-text interface in this part of the discussion. Such interfaces have their own unique challenges but output / provide mostly similar “text” to an NLA. We will also only discuss an English NLA. Language with different glyphs, syntax and grammar have to be dealt with separately.



NLP is a cross discipline between Linguistics and Computer Science. It consists of taking raw strings of text of a language, and breaking it down into various components for classification. It usually consists of:

  • Sentence boundary detection (finding the unique sentences in some text)
  • Syntactic analysis (“tagging” the nouns and verbs)
  • Special Entity Recognition (finding dates and times, and time-intervals and putting them into a local context)
  • Named Entity Recognition (NER) (recognizing names of places, people, etc.)

and sometimes

  • Semantic analysis (assigning meaning to words in their context)
  • Pragmatic analysis (finding the meaning of a sentence as a whole)


These last two classifications are still at the forefront of research. Google made some strides using Word2Vec [1] in the early 2010s and some work has progressed this into Sentence2Vec [2]. These methods represents words, and complete sentence structures in higher dimensional vector spaces (300 up to 3000 dimensions aren’t uncommon).



However, meaningful inferences cannot be made using such structures. Euclidean distance, and cosine differences between vectors don’t work well in higher dimensional spaces [3].

Intent Matching


Neural networks are an integral part these days in intent matching [4]. I have created a sophisticated training-set balancing, targeted synonym expansion, and automatic neural-network deployment software to make it all look seamless.



I never got word/sentence vectors to work [3], although I built a prototype using a ball-tree for storing/retrieving higher dimensional objects efficiently.

NLP and the Serverless Architecture


Bots and NLP pipelines are now commercialized. Any of the popular cloud platforms and IBM’s Watson are bots and NLP pipelines for hire.



However, these systems with all their sophistication have limitations [5]. They usually support NER libraries and editors but not semantic hierarchies. For instance, rather than having a set of named entities, it might be just as easy to encode the extra relationship information in a hypernym (generalization) graph.




Such a structure is arbitrary, but so is language in the end [6]. Let us look at a more traditional software architecture vs an modern n-tier architecture [7].






This diagram was borrowed from “Using Kotlin in a Serverless Architecture with AWS Lambda” [8]. The right hand side represents the more modern Serverless architecture with its layers divided into disconnected tiers. An API facade abstracts the services and proxy-services.


Why is this focus on the architecture so important? First of all, I put it that the Lambda’s and NLP services provided by external platforms aren’t powerful nor customizable enough. One could still use these services as part of some pipe-line, but they do not form a “complete” pipeline that meets all our requirements.



Such requirements include:



  • custom grammatical analysis of special concepts (e.g. GST numbers, phone numbers, date)
  • date-time and date-range language requirements
  • filtering out of date-time and date-ranges pre- the intent
  • creating user contexts stack (i.e. what the topics we “understand” the user has been on about and in what order (most recently used being a top priority)
  • custom semantic markup of concepts including multi-noun concepts (e.g. “bank teller”). This is akin to NER but more sophisticated
  • what I call “aware synonyms”, a machine learning system that assigns “word expansions” to the context of a conversation.

And only once these requirements have been met, can one effectively start looking at matching meaning to intent. Once this is done, we go from intent to action. This we’ll discuss some more in part 3, as this is where the real magic starts happening.



References
